Spring Boot · part 1 of 8

Rebuilding Laravel E-Learning to Java Spring Boot & React: Enterprise Architecture & Cloud-Ready Migration

A comprehensive guide on rebuilding a monolithic Laravel E-Learning & CBT platform into a high-concurrency, cloud-ready architecture using Java 21, Spring Boot 3.4, React 19, Tailwind CSS v4, Redis, and WebSocket STOMP proctoring.

Muhammad Fari Madyan

· 12 min read

Baca dalam Bahasa Indonesia →

The Motivation: From School Monolith to High-Concurrency Enterprise CBT

Earlier in this blog series, I documented the complete transformation of my 2017 legacy junior high school examination platform from Laravel 5.2 to modern Laravel 13, Filament 3, and Livewire 3 (open-sourced at mfarim/laravel-elearning).

That monolithic Laravel rebuild delivered a lot of value:

  • Filament 3 gave us admin CRUD almost instantly.
  • Livewire 3 brought reactive student exam timers and question switching without complex client-side build pipelines.
  • Pest PHP provided solid feature and security regression tests (including the IDOR fixes in Part 10).

However, as the deployment grows from a single junior high school to multi-school academic districts, centralized national certification tests, and large-scale simultaneous CBT (Computer Based Test) sessions, new architectural bottlenecks appear:

  1. The "Exam Rush Hour" Concurrency Surge: When 2,000 to 10,000 candidates click "Start Exam" at exactly 08:00:00 AM, each PHP-FPM process uses a substantial amount of resident memory (typically 40MB–80MB per worker). Spawning thousands of synchronous PHP workers hits OS process limits and drives up CPU context-switching overhead.
  2. Real-Time Proctoring at Scale: Teachers supervising 50–100 students per exam hall need continuous live telemetry (time remaining, current question, anti-cheat violations, tab changes). Running bidirectional, stateful real-time pipelines across thousands of active exam sessions requires an event-driven, memory-efficient message broker.
  3. Decoupled Multi-Client Ecosystem: Modern schools want dedicated mobile applications (Android / iOS / CBT lockdown browsers) and progressive web apps that all consume the same strongly typed REST & WebSocket endpoints.
  4. Strict Enterprise Type Safety & Compliance: Enterprise academic institutions require compile-time type verification across domain models, audit logs, and declarative role-based method security (@PreAuthorize).

To meet these needs, I built a high-performance, decoupled companion platform: Java Spring Boot + React E-Learning.

┌─────────────────────────────────────────────────────────────────────────────┐ │ ARCHITECTURAL EVOLUTION OVERVIEW │ ├──────────────────────────────────────┬──────────────────────────────────────┤ │ SOURCE: Monolithic Stack │ TARGET: Decoupled Enterprise Stack │ │ (https://github.com/mfarim/ │ (https://github.com/mfarim/ │ │ laravel-elearning) │ spring-elearning-react) │ ├──────────────────────────────────────┼──────────────────────────────────────┤ │ • Laravel 13 & PHP 8.3 │ • Java 21 LTS & Spring Boot 3.4.3 │ │ • Server-Side Blade & Livewire 3 │ • React 19 + TypeScript + Vite 6 │ │ • Filament 3 Admin Panel │ • Custom Tailwind CSS v4 Dashboards │ │ • Stateful Sessions & CSRF Cookies │ • Stateless JWT (JJWT 0.12) + RBAC │ │ • Laravel Reverb / Pusher WebSockets │ • Spring STOMP Broker (/ws/cbt) │ │ • Eloquent ORM & Laravel Migrations │ • Spring Data JPA + Hibernate + Flyway│ │ • MySQL 8 Database │ • PostgreSQL 16 + Redis 7 Cache │ │ • Maatwebsite / PhpSpreadsheet │ • Apache POI Batch XLSX Importer │ └──────────────────────────────────────┴──────────────────────────────────────┘

Architectural Comparison: Monolith vs. Decoupled Service

Here is how each critical layer changes between the two architectures:

Architectural ConcernLaravel Monolithic EditionJava Spring Boot + React Edition
Language & RuntimePHP 8.3 (Interpreted / JIT), PHP-FPM process-per-requestJava 21 LTS (HotSpot JVM + Virtual Threads / Project Loom)
Backend FrameworkLaravel 13 MonolithSpring Boot 3.4.3 (RESTful API micro-architecture)
Frontend FrameworkBlade templates + Livewire 3 reactive server componentsReact 19 SPA + TypeScript + Vite 6 + Tailwind CSS v4
AuthenticationStateful PHP session cookies + CSRF tokensStateless JWT Bearer tokens with Impersonation Engine
AuthorizationLaravel Gate & Model Policies (#[Authorize])Spring Security 6 Filter Chain + @PreAuthorize method security
Database & MigrationsMySQL 8 with Laravel Artisan migrationsPostgreSQL 16 with Flyway versioned SQL migrations (V1__...)
Caching LayerRedis cache via Laravel Cache facadeRedis 7 via Spring Data Redis & Lettuce connection pool
Real-Time TelemetryLaravel Reverb / Echo clientSpring WebSocket STOMP message broker (/ws/cbt) + SockJS
Batch ProcessingLaravel Queues + PhpSpreadsheetApache POI batch importer for student & question .xlsx
API DocumentationScramble / Scribe OpenAPI generatorSpringdoc OpenAPI 3 + Swagger UI interactive explorer
Deployment ModelSingle container / Linux VPS systemd unitMulti-container Docker Compose (Nginx, React, Spring Boot, Postgres, Redis)

Update (Nov 2026): A few rows above no longer match the code; I corrected them in Part 8. Redis is not a cache: it stores refresh-token IDs for rotation and revocation, and can optionally share rate-limit counters and live exam events between instances (Part 7). The STOMP broker is Spring's in-memory simple broker, the backend is a modular monolith (one Spring Boot service, not micro-services), and it now runs on Spring Boot 3.5.7.


System Architecture Diagram

Below is the decoupled cloud-ready architecture implemented in the Java Spring Boot + React repository:

┌───────────────────────────────┐ │ CLIENT LAYER (SPA) │ │ React 19 + Tailwind CSS v4 │ └───────────────┬───────────────┘ │ HTTPS (REST) / WSS (WebSocket) │ ▼ ┌─────────────────────────────────────────────────────────────────────────────────────────────────┐ │ SPRING BOOT 3.4 BACKEND │ │ │ │ ┌───────────────────────────────────────────────────────────────────────────────────────────┐ │ │ │ SECURITY & GATEWAY LAYER │ │ │ │ • JwtAuthenticationFilter (Stateless Bearer Validation) │ │ │ │ • DaoAuthenticationProvider + BCrypt Password Encoder │ │ │ │ • Method-level RBAC: @PreAuthorize("hasRole('ADMIN') or hasRole('TEACHER')") │ │ │ │ • One-Click Account Impersonation (/api/v1/auth/admin/impersonate/{userId}) │ │ │ └─────────────────────────────────────────────┬─────────────────────────────────────────────┘ │ │ │ │ │ ┌──────────────────────────────────────┼──────────────────────────────────────┐ │ │ ▼ ▼ ▼ │ │ ┌──────────────┐ ┌──────────────┐ ┌──────────────┐ │ │ │ User & Auth │ │ Academic & │ │ CBT Exam & │ │ │ │ Controller │ │ Learning │ │ Proctoring │ │ │ │ - Students │ │ - Classroom │ │ - Runner API │ │ │ │ - Teachers │ │ - Materials │ │ - Anti-Cheat │ │ │ │ - Impersonate│ │ - Assignment │ │ - Live STOMP │ │ │ └──────┬───────┘ └──────┬───────┘ └──────┬───────┘ │ │ │ │ │ │ │ ▼ ▼ ▼ │ │ ┌───────────────────────────────────────────────────────────────────────────────────────────┐ │ │ │ BUSINESS LOGIC & SERVICE LAYER │ │ │ │ • StudentService (Apache POI Batch Excel Importer) │ │ │ │ • ExamRunnerService (Auto-Scoring, Essay Queue, Synchronized Remaining Seconds) │ │ │ │ • ExamRealtimeService (SimpMessagingTemplate push to /topic/exams/{id}/telemetry) │ │ │ └─────────────────────────────────────────────┬─────────────────────────────────────────────┘ │ │ │ │ │ ┌──────────────────────────────────────┴──────────────────────────────────────┐ │ │ ▼ ▼ │ │ ┌──────────────────────────────┐ ┌─────────────────┐ │ │ │ PERSISTENCE LAYER │ │ CACHE & BROKER │ │ │ │ Spring Data JPA + Hibernate │ │ Redis 7 Cache │ │ │ │ Hikari Connection Pool │ │ STOMP /ws/cbt │ │ │ └──────────────┬───────────────┘ └─────────┬───────┘ │ └─────────────────┼─────────────────────────────────────────────────────────────────────┼─────────┘ │ │ ▼ ▼ ┌────────────────────────┐ ┌────────────────────────┐ │ PostgreSQL 16 │ │ Teacher Proctoring │ │ Flyway SQL Migrations │ │ Live Telemetry Screen │ └────────────────────────┘ └────────────────────────┘

Key Engineering Highlights & Deep Dive

1. Spring Security 6: Stateless JWT with Impersonation Engine

In Laravel, role switching or admin impersonation typically uses Auth::loginUsingId($targetUserId) backed by server sessions. A decoupled single-page application (SPA) needs stateless JWT tokens that carry immutable claims and still support on-demand impersonation.

Here is the production configuration from backend/src/main/java/com/elearning/config/SecurityConfig.java:

JAVA
@Configuration
@EnableWebSecurity
@EnableMethodSecurity
@RequiredArgsConstructor
public class SecurityConfig {

    private final JwtAuthenticationFilter jwtAuthenticationFilter;
    private final CustomUserDetailsService userDetailsService;

    @Bean
    public SecurityFilterChain securityFilterChain(HttpSecurity http) throws Exception {
        http
            .cors(cors -> cors.configurationSource(corsConfigurationSource()))
            .csrf(AbstractHttpConfigurer::disable)
            .sessionManagement(session -> session.sessionCreationPolicy(SessionCreationPolicy.STATELESS))
            .authorizeHttpRequests(auth -> auth
                .requestMatchers(
                    "/api/v1/auth/**",
                    "/swagger-ui/**",
                    "/v3/api-docs/**",
                    "/ws/**"
                ).permitAll()
                .requestMatchers("/api/v1/admin/**").hasRole("ADMIN")
                .requestMatchers("/api/v1/teacher/**").hasAnyRole("ADMIN", "TEACHER")
                .requestMatchers("/api/v1/student/**").hasAnyRole("ADMIN", "STUDENT")
                .anyRequest().authenticated()
            )
            .authenticationProvider(authenticationProvider())
            .addFilterBefore(jwtAuthenticationFilter, UsernamePasswordAuthenticationFilter.class);

        return http.build();
    }
}

The Impersonation Engine

When an administrator needs to investigate a problem with a student's exam, they can issue a targeted impersonation token:

JAVA
@PostMapping("/admin/impersonate/{userId}")
@PreAuthorize("hasRole('ADMIN')")
public ResponseEntity<ApiResponse<AuthResponse>> impersonate(
        @PathVariable Long userId,
        @AuthenticationPrincipal UserPrincipal adminPrincipal) {

    // Generate valid scoped token bearing target's roles with original admin audit claim
    AuthResponse response = authService.impersonate(userId, adminPrincipal);

    return ResponseEntity.ok(ApiResponse.success(response, "Impersonation started successfully"));
}

2. High-Precision CBT Exam Engine: Anti-Cheat & Real-Time Telemetry

The exam runner in backend/.../modules/exam/service/ExamRunnerService.java enforces strict server-side rules that client-side browser clocks cannot manipulate:

Server-Driven Timer Calculation

JAVA
private long calculateRemainingSeconds(Examination exam, ExamAttempt attempt, LocalDateTime now) {
    LocalDateTime examDeadline = attempt.getStartedAt().plusMinutes(exam.getDurationMinutes());

    // Hard boundary: exam cannot exceed global scheduled cutoff time
    if (exam.getEndAt() != null && exam.getEndAt().isBefore(examDeadline)) {
        examDeadline = exam.getEndAt();
    }

    return Math.max(0, Duration.between(now, examDeadline).getSeconds());
}

Anti-Cheat Proctoring with WebSocket STOMP

In frontend/src/pages/exams/ExamRunner.tsx, the React runner locks down the candidate's browser window:

  • Disables right-click context menus (e.preventDefault()).
  • Monitors visibility changes via the HTML5 visibilitychange API.
  • Increments the security violation counter on the server. When violations reach 5, the exam is finalized automatically.
TYPESCRIPT
// React 19 Frontend: Tab switch & minimization telemetry push
useEffect(() => {
  const handleVisibilityChange = () => {
    if (document.hidden && attemptIdRef.current && !submittedResult) {
      api.post(`/exams/attempts/${attemptIdRef.current}/violation`, {
        reason: 'TAB_SWITCH_OR_MINIMIZED',
      }).then((res) => {
        const count = res.data.data.violations;
        setViolations(count);
        if (count >= 5) {
          alert('Security limit reached: 5 violations detected. Auto-submitting exam.');
          handleSubmitExam();
        }
      });
    }
  };

  document.addEventListener('visibilitychange', handleVisibilityChange);
  return () => document.removeEventListener('visibilitychange', handleVisibilityChange);
}, [submittedResult]);

At the same time, the Spring backend broadcasts telemetry packets to every connected teacher supervisor screen:

JAVA
realtimeService.broadcastExamEvent(exam.getId(), "STUDENT_VIOLATION", Map.of(
        "attemptId", attempt.getId(),
        "studentId", student.getId(),
        "studentName", student.getUser().getName(),
        "violations", attempt.getViolations(),
        "timestamp", LocalDateTime.now()
));

The teacher's proctoring monitor dashboard (ExamMonitor.tsx) receives these STOMP messages with sub-millisecond latency and renders live progress bars and alert badges without polling the server.


3. Apache POI: Batch Processing with Row-Level Validation

Importing large Excel spreadsheets (e.g. 5,000 enrolled students or 500 complex exam questions) often crashes monolithic PHP workers, which run out of memory_limit while parsing the XML trees.

In Spring Boot, we use Apache POI with row-level validation:

JAVA
@Transactional
public BatchImportResult importStudentsFromExcel(MultipartFile file, Long classroomId) throws IOException {
    Classroom classroom = classroomRepository.findById(classroomId)
            .orElseThrow(() -> new ResourceNotFoundException("Classroom not found"));

    int successCount = 0;
    List<String> errors = new ArrayList<>();

    try (Workbook workbook = new XSSFWorkbook(file.getInputStream())) {
        Sheet sheet = workbook.getSheetAt(0);

        for (int i = 1; i <= sheet.getLastRowNum(); i++) {
            Row row = sheet.getRow(i);
            if (row == null) continue;

            try {
                String name = getCellValue(row.getCell(0));
                String email = getCellValue(row.getCell(1));
                String nis = getCellValue(row.getCell(2));

                provisionStudentAccount(name, email, nis, classroom);
                successCount++;
            } catch (Exception e) {
                errors.add("Row " + (i + 1) + ": " + e.getMessage());
            }
        }
    }

    return new BatchImportResult(successCount, errors);
}

Note that XSSFWorkbook loads the whole workbook into memory, so this is batch processing, not streaming. For very large files, switch to a streaming reader such as Apache POI's SAX-based event API (XSSFReader).


4. Database Schema: PostgreSQL & Flyway Versioning

Unlike Laravel migrations, which execute PHP code, Java enterprise backends prefer immutable, declarative SQL scripts managed by Flyway.

In backend/src/main/resources/db/migration/V1__initial_schema.sql:

SQL
CREATE TABLE examinations (
    id BIGSERIAL PRIMARY KEY,
    title VARCHAR(255) NOT NULL,
    description TEXT,
    subject_id BIGINT NOT NULL REFERENCES subjects(id) ON DELETE CASCADE,
    teacher_id BIGINT NOT NULL REFERENCES teachers(id) ON DELETE CASCADE,
    classroom_id BIGINT NOT NULL REFERENCES classrooms(id) ON DELETE CASCADE,
    duration_minutes INT NOT NULL DEFAULT 60,
    passing_score INT NOT NULL DEFAULT 75,
    randomize_questions BOOLEAN DEFAULT FALSE,
    randomize_options BOOLEAN DEFAULT FALSE,
    allow_review BOOLEAN DEFAULT TRUE,
    start_at TIMESTAMP NOT NULL,
    end_at TIMESTAMP NOT NULL,
    created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    updated_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP
);

CREATE TABLE exam_attempts (
    id BIGSERIAL PRIMARY KEY,
    examination_id BIGINT NOT NULL REFERENCES examinations(id) ON DELETE CASCADE,
    student_id BIGINT NOT NULL REFERENCES students(id) ON DELETE CASCADE,
    attempt_number INT NOT NULL DEFAULT 1,
    status VARCHAR(30) NOT NULL DEFAULT 'in_progress',
    score INT,
    passed BOOLEAN,
    violations INT DEFAULT 0,
    started_at TIMESTAMP NOT NULL,
    finished_at TIMESTAMP,
    CONSTRAINT uk_exam_student_attempt UNIQUE (examination_id, student_id, attempt_number)
);

The unique constraint uk_exam_student_attempt prevents race conditions in which a double-submitted request creates two rows with the same attempt number for one candidate. Because the key includes attempt_number, it does not block a new parallel attempt on its own; the service layer still has to check for an existing in_progress attempt.


Frontend Architecture: React 19, Vite & Tailwind CSS v4

The frontend application (frontend/) is built for speed, clean UX, and full mobile responsiveness:

  1. State Management: Zustand stores manage JWT persistence and user context across browser tabs without prop-drilling.
  2. Dynamic Mobile Drawer: On student mobile screens, navigation and exam details collapse into an accessible sliding drawer.
  3. CBT Question Palette: Fast keyboard and touch navigation between 100+ exam questions with visual state indicators:
    • 🟢 Green: Answered and synchronized to server
    • ⚪ Gray: Unanswered question
    • 🟡 Yellow: Active question under review
  4. Exam Hall Ticket Generator: Print-ready candidate cards with auto-rendered SVG barcodes for check-in at the official exam venue.

When to Use Laravel Monolith vs. Java Spring Boot + React

The right architectural stack depends on your operational constraints:

Scenario / RequirementRecommended StackRationale
Single School / Small Academy (< 1,000 users)Laravel 13 + Livewire + FilamentFastest delivery time, minimal DevOps overhead, single codebase, batteries-included admin CRUD.
District-Wide Exams / University CBT (> 10,000 concurrent)Java 21 Spring Boot + React 19JVM Virtual Threads handle mass concurrent I/O with low RAM. Independent horizontal scaling of API and SPA.
Native Mobile App Ecosystem (iOS/Android/Desktop)Java Spring Boot API + ReactSingle backend API serves web portal, native mobile apps, and third-party lockdown exam browsers.
Small Solo Engineering TeamLaravel 13 MonolithFull-stack productivity without maintaining separate TypeScript DTO schemas, CORS configurations, and dual CI/CD pipelines.
Enterprise Compliance & Strict AuditingJava Spring BootStrong static typing, declarative @PreAuthorize security, enterprise Redis/Kafka integration, and long-term LTS enterprise support.

Open-Source Repositories

Both companion implementations are public, so you can study them, adapt them, and deploy them to production:


Summary & Next Steps

Rebuilding the Laravel E-Learning platform with Java Spring Boot and React shows that modern software engineering is not about dogma. It is about choosing the right toolchain for each operational scale. Laravel offers unmatched development speed, while Spring Boot and React deliver enterprise concurrency, resilient real-time proctoring, and cloud-native decoupled scalability.

In Part 2, we will audit this codebase for production readiness: closing a path traversal hole in file storage, stopping error messages from leaking internals, adding refresh tokens so 15-minute access tokens don't kick students out mid-exam, and making the Docker setup resilient. Stay tuned!
